Float & Board Level Indicator

About Float & Board Level Indicator

Float and Chord Level Indicator means of measuring liquid level in large storage tanks. The level of liquid can be physically read even from a greater distance, by noting the position of pointer moving up and down on scale board.

Float devices use the buoyancy of a float to indi-cate the liquid level in the tank. One common ap-proach is to attach the float to a chain. The chain is attached to a counterweight which indicates the level as the float moves up and down. These types of device are often found on large atmospheric storage tanks.

Scales are marked in cms, in reverse order, zero level marking on top and total tank height in cms at bottom. PP construction for acid ap-plication is also available. Indicators are manufactured in different operating ranges as per tank heights for both underground & overhead tanks in either vertical or horizontal tanks.

Large level measurements, wire-guided float detectors can be used. The guide wires are connected to top and bottom anchors and assist in positioning the float as it moves with the fluid level. The tape is connected to the top of the float and runs directly up and over pulleys then down to the gauging head which is outside the tank at a suitable level for viewing.

Application:

• Storage Tanks, Large Oil and Liquid tanks, FO Oil, Acids, Chemical, Diesel etc

Features:

• Suitable for large storage tanks
• For Overhead and Underground Tanks
